What's the model number?

Model number SUR26, UPC 044315814303, our SKU 8229437.

Simpson Strong-Tie SUR SUR26 Hanger, 5 in H, 2 in D, 1-9/16 in W, Steel, Galvanized/Zinc, Face Mounting

Model: SUR26
UPC: 044315814303
Our SKU: 8229437
Sold by: EA
Factory pack: 25

Skewed right
These hangers will normally accommodate a 40 to 50 deg skew
The joist end may be square cut or bevel cut
Angled nail slots direct nails for proper installation
Made from 16 ga steel
Galvanized (G90) for extra corrosion resistance
Features obround nail holes on the acute side, allowing nails to be easily installed parallel to the joist
Features positive-angle nailing for engineered-wood sizes to prevent wood splitting and to speed installation

The SUR/L are 45 deg skewed hangers designed to support solid sawn and engineered-wood products used in wood construction. These U-shaped hangers encapsulate the top-flange of the joist, so no web stiffeners are required for standard installation.

$10.99per eachLaunch price

Special orderSpecial order. We'll call you with a date

Minimum order 25

$274.75 for 25 EA : $10.99 each

This item is ordered in 25s. 25 is the smallest quantity we can supply, and quantities go up in 25s.

Special orderSpecial order. We'll call you with a date

Quantity

25 special order, 1 to 2 weeks

Availability

Special order, 1 to 2 weeks

Delivery

2 to 4 days from another distribution center

Not on the store truck

Model: SUR26
UPC: 044315814303
Our SKU: 8229437
Sold by: EA
Factory pack: 25

Product highlights

Width

1-9/16

Depth

Material

Steel

Finish

Galvanized/Zinc

Fastener Type

Mounting Type

Skew Angle

45 deg

Specifications (15)

Full product specifications
Depth	2 in
Fastener Type	Nail
Finish	Galvanized/Zinc
Material	Steel
Mounting Type	Face
Skew Angle	45 deg
Width	1-9/16
Weight	0.64 lb
Length (shipping)	13 in
Width (shipping)	8 in
Height (shipping)	7 in
Sold as	Sold by the ea
Factory pack	25
Country of origin	US
Shipping dimensions	13 in long by 8 in wide by 7 in high

Documents

Simpson Strong-Tie 2024 Catalog (PDF)

Product description

Made of steel with a galvanized/zinc finish, measuring 2 in deep, with fastener type Nail, mounting type Face, skew angle 45 deg.

Application

For wood framing

Skewed right
These hangers will normally accommodate a 40 to 50 deg skew
The joist end may be square cut or bevel cut
Angled nail slots direct nails for proper installation
Made from 16 ga steel
Galvanized (G90) for extra corrosion resistance
Features obround nail holes on the acute side, allowing nails to be easily installed parallel to the joist
Features positive-angle nailing for engineered-wood sizes to prevent wood splitting and to speed installation

About this item

What is this?: Simpson Strong-Tie SUR SUR26 Hanger, 5 in H, 2 in D, 1-9/16 in W, Steel, Galvanized/Zinc, Face Mounting. Listed under Joist Hangers.
What is it made of?: Material: Steel.
What size is it?: Depth 2 in.
What is it used for?: For wood framing
How fast can I get it?: 2 to 4 days from another distribution center.
What's the model number?: Model number SUR26, UPC 044315814303, our SKU 8229437.
