Shipping carton measures 20.75 in long by 16.375 in wide by 6.315 in high.

What's the model number?

Model number E4RTATSB, UPC 080083751501, our SKU 8753030.

Halo E4RTATSB Recessed Housing, 11.5 in L x 4.62 in W x 5 in H Dimensions, Remodel Construction, 4 in Dia Recessed Can

Model: E4RTATSB
UPC: 080083751501
Our SKU: 8753030
Sold by: EA
Factory pack: 6

Remodel housing design installs from below the finished ceiling
Remodel springs accommodate 1/2 in and 5/8 in ceiling material
AIR-TITE™ exclusive housing gasket
Hinged junction box with Slide-N-Side
Socket bracket adjusts lamp to various trim styles and designs
AIR-TITE™ gasket pre-installed on remodel flange
Four remodel clips secure housing and accommodates 1/2 and 5/8 in ceiling material
Seven conduit knockouts are uniform 1/2 in size with true pryout slots
Four pry-outs with integral strain relief simplify NM non-metallic sheathed cable installation
Adjustable position bracket with porcelain socket and nickel-plated brass screw shell provides flexibility in lamp positioning

The E4RTATSB is a compact and efficient recessed remodel housing optimized and listed for EISA compliant tungsten-Halogen lamps, as well as Incandescent, CFL and LED lamps. Housing is suitable for residential or light commercial applications. For installation in insulated ceilings and non-insulated ceilings with airtight code compliant construction. Use with a variety of trims and finishes to create different lighting effects or to match any decor. May be retrofit with compatible Halo®LED lighting systems.

$26.99per eachLaunch price

Special orderSpecial order. We'll call you with a date

Quantity

1 special order, 1 to 2 weeks

Availability

Special order, 1 to 2 weeks

Delivery

2 to 4 days from another distribution center

Not on the store truck

Model: E4RTATSB
UPC: 080083751501
Our SKU: 8753030
Sold by: EA
Factory pack: 6

Product highlights

Recessed Can Diameter

Ceiling Opening Size

4-1/4 in

Material

Steel

Ceiling Type

Non-Insulated

Construction Type

Remodel

Dimensions

11.5 in L x 4.62 in W x 5 in H

Includes

(3) Push Wire Nuts (3) Wire Connectors Clear Caps

Mounting Type

Recessed

Specifications (17)

Full product specifications
Ceiling Opening Size	4-1/4 in
Ceiling Type	Non-Insulated
Construction Type	Remodel
Dimensions	11.5 in L x 4.62 in W x 5 in H
Includes	(3) Push Wire Nuts (3) Wire Connectors Clear Caps
Material	Steel
Mounting Type	Recessed
Recessed Can Diameter	4 in
Suitable for	Halo LED Lighting Systems
Weight	1.59 lb
Length (shipping)	20.75 in
Width (shipping)	16.375 in
Height (shipping)	6.315 in
Sold as	Sold by the ea
Factory pack	6
Country of origin	MX
Shipping dimensions	20.75 in long by 16.375 in wide by 6.315 in high

Documents

Cooper Lighting E4RTATSB Data Sheet (PDF)

Product description

Made of steel, with ceiling opening size 4-1/4 in, ceiling type Non-Insulated, construction type Remodel.

Application

For commercial and residential applications

Remodel housing design installs from below the finished ceiling
Remodel springs accommodate 1/2 in and 5/8 in ceiling material
AIR-TITE™ exclusive housing gasket
Hinged junction box with Slide-N-Side
Socket bracket adjusts lamp to various trim styles and designs
AIR-TITE™ gasket pre-installed on remodel flange
Four remodel clips secure housing and accommodates 1/2 and 5/8 in ceiling material
Seven conduit knockouts are uniform 1/2 in size with true pryout slots
Four pry-outs with integral strain relief simplify NM non-metallic sheathed cable installation
Adjustable position bracket with porcelain socket and nickel-plated brass screw shell provides flexibility in lamp positioning

About this item

What is this?: Halo E4RTATSB Recessed Housing, 11.5 in L x 4.62 in W x 5 in H Dimensions, Remodel Construction, 4 in Dia Recessed Can. Listed under Recessed Light Housing.
What is it made of?: Material: Steel.
What size is it?: Shipping carton measures 20.75 in long by 16.375 in wide by 6.315 in high.
What is it used for?: For commercial and residential applications
How fast can I get it?: 2 to 4 days from another distribution center.
What's the model number?: Model number E4RTATSB, UPC 080083751501, our SKU 8753030.
