Length 4-1/2 in, Width 2-3/4 in, Thickness 0.08 in.

How fast can I get it?

In our warehouse. Arrives on the next truck, typically 2 business days : trucks arrive Tuesday, Wednesday, Thursday and Friday.

What's the model number?

Model number STE7W, UPC 032664578502, our SKU 6760821.

Eaton

Eaton STE7W Mid-Size Sectional Wallplate, 4-1/2 in L, 2-3/4 in W, 1-Gang, Polycarbonate, White, High-Gloss

Model: STE7W
UPC: 032664578502
Our SKU: 6760821
Sold by: EA
Factory pack: 50

Polycarbonate single receptacle polycarbonate wallplates are virtually unbreakable, with high-structural rigidity, long term form retention and excellent impact and abrasion resistance
Rugged construction reduces installation cost due to less plate breakage and resists bowing to provide a smooth, flat installation
Exclusive timesaving screw-catch feature that holds mounting screws captive and simplifies installation
High-gloss finish is soil-resistant

End plate. Thermoplastic construction for durability and flexibility. Easy-to snap together and lock. Mid size design to fit over most existing wall openings. Screw catch feature holds already attached mounting screws captive for easy installation. Screws are slotted steel, baked enamel and painted. Meets current Federal specifications as tested to UL 514. Meets all CSA requirements C22.2, No. 42.1, cUL Listed. NEMA WD-1, WD-6. Temperature rating -40 to 65 deg C.

$3.49per eachLaunch price

Next truckIn on Wednesday, Oct 21 : 2 business days

Quantity

1 next truck

Availability

20 on the Wednesday, Oct 21 truck

Delivery

In on Wednesday, Oct 21 : 2 business days

Delivery runs after the truck lands

Model: STE7W
UPC: 032664578502
Our SKU: 6760821
Sold by: EA
Factory pack: 50

Product highlights

Length

4-1/2 in

Width

2-3/4 in

Hole Size

1-13/32 in

Thickness

0.08 in

Material

Polycarbonate

Finish

High-Gloss

Color

White

First Gang to Edge

1-3/8 in

Specifications (20)

Full product specifications
Color	White
Finish	High-Gloss
First Gang to Edge	1-3/8 in
Hole Size	1-13/32 in
Includes	Matching Screws
Length	4-1/2 in
Material	Polycarbonate
Number Of Gangs	1
Operating Temperature	-40 to 70 deg C
Suitable for	Single Receptacle
Thickness	0.08 in
Width	2-3/4 in
Weight	0.07 lb
Length (shipping)	5.875 in
Width (shipping)	6.375 in
Height (shipping)	10.875 in
Sold as	Sold by the ea
Factory pack	50
Country of origin	US
Shipping dimensions	5.875 in long by 6.375 in wide by 10.875 in high

Product description

Made of polycarbonate with a high-gloss finish, measuring 4-1/2 in long by 2-3/4 in wide by 0.08 in thick, with first gang to edge 1-3/8 in, hole size 1-13/32 in, includes Matching Screws.

Polycarbonate single receptacle polycarbonate wallplates are virtually unbreakable, with high-structural rigidity, long term form retention and excellent impact and abrasion resistance
Rugged construction reduces installation cost due to less plate breakage and resists bowing to provide a smooth, flat installation
Exclusive timesaving screw-catch feature that holds mounting screws captive and simplifies installation
High-gloss finish is soil-resistant

About this item

What is this?: Eaton STE7W Mid-Size Sectional Wallplate, 4-1/2 in L, 2-3/4 in W, 1-Gang, Polycarbonate, White, High-Gloss. Listed under Specialty Receptacle Plates.
What is it made of?: Material: Polycarbonate.
What size is it?: Length 4-1/2 in, Width 2-3/4 in, Thickness 0.08 in.
How fast can I get it?: In our warehouse. Arrives on the next truck, typically 2 business days : trucks arrive Tuesday, Wednesday, Thursday and Friday.
What's the model number?: Model number STE7W, UPC 032664578502, our SKU 6760821.
