Shipping carton measures 11 in long by 4 in wide by 6.125 in high.

What's the model number?

Model number TRUSBAC20V-BX-L, UPC 032664025884, our SKU 4896411.

Eaton Cooper Wiring TRUSBAC20 Series TRUSBAC20V-K-L Duplex Receptacle, 2-Pole, 5 A, 125 VAC, 2-USB Port, Type A, C USB

Model: TRUSBAC20V-BX-L
UPC: 032664025884
Our SKU: 4896411
Sold by: EA
Factory pack: 48

Standard AC receptacle with USB and USB-C ports rated at a combined 5.0A
USB-C charging port charges most electronic devices that comply with the USB-C standard
Tamper-resistant shutters provide compliance with 2017 NEC® Article 406.12 that states that all 15 A and 20 A, 125 V receptacles installed in dwelling units must be tamper-resistant
Replaces a standard duplex receptacle
Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure and provides redundant measure of ground continuity where jumper is used
Thermoplastic top and back body are virtually unbreakable to deliver years of durable performance
Steel mounting strap is zinc-plated for added corrosion resistance
Convenient patented built-in wire strippers speed installation
Triple wipe blade contacts and double-wipe ground contacts to insure long term blade retention
Reversible Type C port allows for consistent charging regardless of plug-in orientation

Eaton Cooper Wiring TRUSBAC20 Duplex Receptacle, 125 VAC, 5 A, Frequency Rating: 130 kHz, Number of Poles: 2, Number of Wires: 3, Number of USB Ports: 2, USB Type: Type A, C, Wiring Type: Back, Side, Wire Size: 10 to 14 AWG, NEMA Configuration: NEMA 5-20R, Operating Temperature: -4 to 140 deg F, Strap Mounting, Thermoplastic/Steel, Ivory, Dimensions: 4.19 in H x 1.3 in W x 1.67 in D

$35.99per eachLaunch price

Special orderSpecial order. We'll call you with a date

Quantity

1 special order, 1 to 2 weeks

Availability

Special order, 1 to 2 weeks

Delivery

2 to 4 days from another distribution center

Not on the store truck

Model: TRUSBAC20V-BX-L
UPC: 032664025884
Our SKU: 4896411
Sold by: EA
Factory pack: 48

Product highlights

Wire Size

10 to 14 AWG

Voltage Rating

125 VAC

Material

Thermoplastic/Steel

Color

Ivory

Current Rating

Dimensions

4.19 in H x 1.3 in W x 1.67 in D

Frequency Rating

130 kHz

Mounting Type

Strap

Specifications (23)

Full product specifications
Color	Ivory
Current Rating	5 A
Dimensions	4.19 in H x 1.3 in W x 1.67 in D
Frequency Rating	130 kHz
Material	Thermoplastic/Steel
Mounting Type	Strap
NEMA Configuration	NEMA 5-20R
Number of Poles	2
Number of USB Ports	2
Number Of Wires	3
Operating Temperature	-4 to 140 deg F
USB Type	Type A C
Voltage Rating	125 VAC
Wire Size	10 to 14 AWG
Wiring Type	Back Side
Weight	0.335 lb
Length (shipping)	11 in
Width (shipping)	4 in
Height (shipping)	6.125 in
Sold as	Sold by the ea
Factory pack	48
Country of origin	CN
Shipping dimensions	11 in long by 4 in wide by 6.125 in high

Product description

Made of thermoplastic/steel with a ivory finish, with current rating 5 A, dimensions 4.19 in H x 1.3 in W x 1.67 in D, frequency rating 130 kHz.

Standard AC receptacle with USB and USB-C ports rated at a combined 5.0A
USB-C charging port charges most electronic devices that comply with the USB-C standard
Tamper-resistant shutters provide compliance with 2017 NEC® Article 406.12 that states that all 15 A and 20 A, 125 V receptacles installed in dwelling units must be tamper-resistant
Replaces a standard duplex receptacle
Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure and provides redundant measure of ground continuity where jumper is used
Thermoplastic top and back body are virtually unbreakable to deliver years of durable performance
Steel mounting strap is zinc-plated for added corrosion resistance
Convenient patented built-in wire strippers speed installation
Triple wipe blade contacts and double-wipe ground contacts to insure long term blade retention
Reversible Type C port allows for consistent charging regardless of plug-in orientation

About this item

What is this?: Eaton Cooper Wiring TRUSBAC20 Series TRUSBAC20V-K-L Duplex Receptacle, 2-Pole, 5 A, 125 VAC, 2-USB Port, Type A, C USB. Listed under USB & Combo Receptacles.
What is it made of?: Material: Thermoplastic/Steel.
What size is it?: Shipping carton measures 11 in long by 4 in wide by 6.125 in high.
How fast can I get it?: 2 to 4 days from another distribution center.
What's the model number?: Model number TRUSBAC20V-BX-L, UPC 032664025884, our SKU 4896411.
