Shipping carton measures 6.125 in long by 3.625 in wide by 4.5 in high.

How fast can I get it?

In stock at our 1587 First Avenue store. Order by 10am for same-day delivery anywhere in Manhattan.

What's the model number?

Model number 1877W-BOX, UPC 032664311703, our SKU 6730238.

Eaton Wiring Devices 1877W-BOX Single Receptacle, Flush Mounting, 2-Pole, 125 V, 20 A, Side Wiring, NEMA: NEMA 5-20R

Model: 1877W-BOX
UPC: 032664311703
Our SKU: 6730238
Sold by: EA
Factory pack: 100

Galvanized steel, wraparound yoke mounting strap for excellent assembly security
Extra length or width helps reach large panel cutouts for code compliance
Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure and provides redundant measure of ground continuity where jumper is used
Screw-catch feature on duplex devices speeds mounting of wallplates

Meets all UL 498 requirements. Triple wire line contacts provide excellent long term plug retention. Arc-resistant thermostat face. Side wire terminals accept up to #10 solid or stranded wire. Terminal screws backed out. Tamper-resistant receptacles have a UL listed shutter system. 20 A, 125 V.

$5.49per eachLaunch price

In stock todaySame-day delivery in Manhattan, order by 10am

Quantity

Availability

in store at 1587 First Ave11

at NY Paint & Hardware5

274 more on the Wednesday, Oct 21 truck

Delivery

Same-day delivery in Manhattan, order by 10am

$35 in Manhattan, free at $250+

Model: 1877W-BOX
UPC: 032664311703
Our SKU: 6730238
Sold by: EA
Factory pack: 100

Product highlights

Wire Size

14 to 10 AWG

Voltage Rating

125 V

Material

Color

White

Current Rating

Dimensions

3.28 in L x 1.31 in W x 0.83 in D

Includes

Screws

Mounting Type

Flush

Specifications (21)

Full product specifications
Color	White
Current Rating	20 A
Dimensions	3.28 in L x 1.31 in W x 0.83 in D
Includes	Screws
Material	PVC
Mounting Type	Flush
NEMA Configuration	NEMA 5-20R
Number of Poles	2
Number Of Wires	3
Operating Temperature	-4 to 140 deg F
Voltage Rating	125 V
Wire Size	14 to 10 AWG
Wiring Type	Side
Weight	0.144 lb
Length (shipping)	6.125 in
Width (shipping)	3.625 in
Height (shipping)	4.5 in
Sold as	Sold by the ea
Factory pack	100
Country of origin	CN
Shipping dimensions	6.125 in long by 3.625 in wide by 4.5 in high

Product description

Made of pvc with a white finish, with current rating 20 A, dimensions 3.28 in L x 1.31 in W x 0.83 in D, includes Screws.

Application

For commercial and residential applications

Galvanized steel, wraparound yoke mounting strap for excellent assembly security
Extra length or width helps reach large panel cutouts for code compliance
Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure and provides redundant measure of ground continuity where jumper is used
Screw-catch feature on duplex devices speeds mounting of wallplates

About this item

What is this?: Eaton Wiring Devices 1877W-BOX Single Receptacle, Flush Mounting, 2-Pole, 125 V, 20 A, Side Wiring, NEMA: NEMA 5-20R. Listed under Single Receptacles.
What is it made of?: Material: PVC.
What size is it?: Shipping carton measures 6.125 in long by 3.625 in wide by 4.5 in high.
What is it used for?: For commercial and residential applications
How fast can I get it?: In stock at our 1587 First Avenue store. Order by 10am for same-day delivery anywhere in Manhattan.
What's the model number?: Model number 1877W-BOX, UPC 032664311703, our SKU 6730238.
